KWSE30-HL
Recirculating ball bearing carriage
High, narrow, long carriage for six-row linear recirculating ball bearing and guideway assembly
Main Dimensions & Performance Data
| H | 45 mm | Height system |
| B | 60 mm | Width carriage |
| L | 119.3 mm | Overall length carriage |
| I C | 51,000 N | Dynamic load rating, load direction I: compressive load |
| I C0 | 113,000 N | Static load rating, load direction I: compressive load |
| II C | 48,000 N | Dynamic load rating, load direction II: tensile load |
| II C0 | 85,000 N | Static load rating, load direction II: tensile load |
| III C | 50,000 N | Dynamic load rating; basic dynamic load rating, Load direction III: lateral load |
| III C0 | 88,000 N | Static load rating, Load direction III: lateral load |
| ≈m | 1.2 kg | Weight |
Mounting dimensions
| A1 | 16 mm | Distance from locating edge on carriage to locating edge on guideway |
| JB | 40 mm | |
| b | 28 mm | Width rail |
| A2 | 10 mm | Distance from locating edge to hole |
| L1 | 95.3 mm | |
| JL | 60 mm | |
| H1 | 5.4 mm | Free space, system dimension |
| H5 | 6 mm | |
| T5 | 11 mm | Thread depth |
| G2 | M8 | Fixing screws below (DIN ISO 4762-12.9) |
| G2 MA | 41 Nm | Maximum tightening torque |
| N2 | 4.5 mm | Max. diameter of lubrication hole in adjacent construction |
| JL5 | 22.65 mm | Position lubrication connector |
| A3 | 9.5 mm | Position lubrication connector |
| t A3 | 7 mm | Maximum permissible screw depth for lubrication connectors |
| O | 4,5x1,5 | O-Ring DIN 3771 |
| M0X | 1,920 Nm | Moment |
| M0Y | 1,540 Nm | Moment |
| M0Z | 1,360 Nm | Moment |
Additional information
| VMKB_065 | KWSE | Material name |
Downloads:
Your current product variant
| Size code | 30 | |
| Carriage design | HL | High, long carriage |
